GraphMLViewer

Dostępny powyżej tygodnia
W magazynie: Dostępny (100 szt.)

ySVG Extension Package


The ySVG extension package adds support for Scalable Vector Graphics (SVG) format to the yFiles for Javagraph visualization library.

The current ySVG version is 2.4.0.1. Please refer to the release notes to learn more about the technical requirements and feature enhancements of this latest version.

Features

  • An extensible SVG and SVGZ (Zip-compressed SVG) writer for yFiles Graph2D objects that makes it possible to add hyperlinks, rollover effects, and other useful features to the generated SVG diagrams. Thedemo section explains how to extend the SVG output process.
  • The possibility to define the appearance of nodes in SVG format using a specialized yFilesNodeRealizer.

SVG Sample
Show SVG sample

Click on the image to see an SVG diagram generated with ySVG. You need to have an SVG viewer plugin installed to view the diagram or a browser with native SVG support. The SVG viewer plugin can be obtained from Adobe for Windows and Mac OS operating systems.
